How to Choose the Best Aluminum Alloy? Ming Ming Aluminum Industry Analyzes the Performance and Applications of Gravity Casting Materials

As experts in gravity casting of aluminum alloys in Taiwan, Ming Ming Aluminum frequently assists clients with material evaluation. Choosing the right alloy grade is the first step in determining the strength, lifespan, corrosion resistance, and even cost-effectiveness of the casting. Today, we'll introduce you to some of the most common aluminum alloys used in gravity casting and how to make an informed choice based on their properties.

Among the many aluminum alloy series, aluminum-silicon (Al-Si) alloys are undoubtedly the stars in gravity casting. Their popularity is primarily due to their superior castability. The addition of silicon significantly improves the fluidity of molten aluminum, allowing it to smoothly fill all corners of the mold, while reducing shrinkage during solidification, thus minimizing casting defects and resulting in high-quality, dense castings. *While aluminum-silicon alloys offer excellent castability, a minimum wall thickness of 4.5mm must still be considered under these recasting conditions. Within this large family, grades with the addition of different trace elements are available to meet diverse performance requirements.

• A356 / A357 — The Preferred Choice for High-Performance Gravity Casting
  In the field of gravity casting of aluminum alloys, A356 (Al-Si-Mg) has become the most representative choice due to its excellent comprehensive performance. It possesses excellent castability and corrosion resistance, and its most crucial advantage lies in its excellent response to T6 heat treatment. After T5 or T6 treatment, the tensile strength, yield strength, and hardness of A356 are significantly improved, providing extraordinary mechanical properties. Furthermore, A356 alloys can undergo repeated heat treatments. A357 is an upgraded version of A356 with higher tensile strength, higher purity, and even more superior performance.

  Therefore, when your parts need to withstand high stress, severe vibration, or strong impact, and have stringent requirements for strength, toughness, and long-term reliability, the A356/A357 is the ideal solution. Its applications are extremely wide-ranging, from automotive suspension system parts, high-performance wheel rims, and electric vehicle motor housings, to critical structural components of robotic arms and high-pressure valve bodies.



• ZL104 — A Powerful Performer Combining Strength and Stability
  ZL104 is also a high-performance Al-Si-Mg-Mn alloy. It exhibits excellent overall mechanical properties and airtightness in its cast state and can be further strengthened through heat treatment. Its most prominent feature is its dimensional stability; it is not easily deformed by temperature changes and can maintain precise tolerances for extended periods.

  Therefore, ZL104 is particularly suitable for parts that operate under medium loads and have strict requirements for airtightness and dimensional accuracy. For example, hydraulic pump housings, pneumatic tool parts, engine intake pipes, or precision instrument housings that require high sealing are all classic applications where the characteristics of ZL104 can be fully utilized.


• ADC12 / A380 — A Balance Between Cost and Performance
  ADC12 and A380 are ideal options when cost-effectiveness is a priority. While these two Al-Si-Cu alloys are more commonly used in pressure casting, their excellent flowability and formability also make them suitable for gravity casting, easily handling complex product shapes.

  Their biggest advantage lies in their relatively economical cost. However, it should be noted that due to their copper content, their corrosion resistance is slightly inferior to A356, and their elongation is lower (making them more brittle). Therefore, they are best suited for products that do not require extreme strength and are not suitable for heat treatment, but where excellent formability and budget control are more important. They are commonly used in non-load-bearing functional parts such as brackets, housings, and heat sinks for various equipment.

From high-strength A356 to cost-effective ADC12, each aluminum alloy has its unique value. The best choice begins with a clear definition of your product needs. At Ming Ming Aluminum, we offer more than just casting services; we provide professional material selection consultation. Our team will work with you to analyze the stress conditions, working environment, subsequent processing requirements, and cost budget of your parts, recommending the most suitable aluminum alloy material from the outset to ensure your product has the strongest genes from the very beginning.
